Product description
◎ There are three heating sources: steam, electricity and electric steam.
◎ Service temperature: steam heating 50-140℃, 150℃ higher; Electrically heating at 50-350 DEG C;
◎ The temperature is automatically controlled and recorded by a recorder;
◎ The inner wall of the box body is fully welded, and all transitions are arc transitions without dead ends.
◎ The sealing performance of the whole machine is good, and the unique guide rail sealing device ensures the sealing performance of the whole machine;
◎ The air inlet can be equipped with a high efficiency air filter; The moisture outlet can be matched with a medium-effect air filter.
◎ Mechanical interlocking is realized for the double doors of the door-to-door oven;
◎ All parts in the oven can be quickly disassembled and installed to facilitate cleaning;
◎ The control system is equipped with text display and touch screen to choose from.
Technical specifications
Model specification | Drying quantity per time （kg） | Fan power （kw） | Steam consumption （kg/h） | Drying car （set） | Drying tray (only) | Width × depth × height （mm） | Upper and lower temperatures （℃） |
CT-C-O | 35 | 0.45 | 8 | / | 16 | 1130×1100×1750 | ±2 |
CT-C-I | 120 | 0.45 | 18 | 2 | 48 | 2300×1200×2000 | ±2 |
CT-C-II | 240 | 0.9 | 36 | 4 | 96 | 2300×2200×2000 | ±2 |
CT-C-III | 360 | 1.35 | 54 | 6 | 144 | 3430×2200×2000 | ±2 |
| CT-C-IV | 480 | 1.8 | 72 | 8 | 192 | 4460×2200×2290 | ±2 |
